Midnite Solar Circuit Breaker, 100A 150VDC, 1-Pole, Din Mount, Model MNEPV100
Product details
| Management number | 215635342 | Release Date | 2026/04/12 | List Price | $18.32 | Model Number | 215635342 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
MidNite Solar MNEPV100 Circuit Breaker 100A. MidNite's breakers are rated to break the full rated load at the rated voltage repeatedly, with NO DAMAGE. Always use a properly sized breaker for disconnecting. All MidNite circuit breakers can be used at 100% rated current when mounted in a MidNite enclosure. MNEPV breakers are the same as CBI QY breakers except the standard used is inadequate for the solar industry. MidNite breakers have been evaluated by ETL to 150VDC and are listed for US and Canada. All of the NRTL listings still apply. Breakers ordered under the CBI part numbering system will not be listed for 150VDC and in many cases are not suitable for the solar industry.
- 100 amp Din rail mount breaker. | 10,000 AIC. | Polarized
- Accepts up to #2 wire.
- Breaker Torque Value: 20 In-Lbs (2.3NM)
- Environmental Rating - Type 1 (Indoor)
- Listed for US & Canada
| UPC | 715547542547 |
|---|---|
| Model | MNEPV100 |
| Voltage | 150 Volts |
| Brand Name | MidNite Solar |
| Unit Count | 1.0 Count |
| Item Weight | 9.6 ounces |
| Part Number | MNEPV100 |
| Manufacturer | MidNite Solar |
| Mounting Type | DIN Rail Mount |
| Current Rating | 100 Amps |
| Number of Poles | 1 |
| Circuit Breaker Type | Standard |
