DSE6110 MKIII Original Made in UK Deep sea Auto Start Control Module Generator Controller Diesel Genset Spare Parts PEMP

DSE6110 MKIII Original Made in UK Deep sea Auto Start Control Module Generator Controller Diesel Genset Spare Parts PEMP DSE6110 MKIII Auto Start Control Module The DSE6110 MKIII is an Auto Start Control Module suitable for a wide variety of single, diesel or gas, genset applications. Monitoring an extensive number of engine parameters, the module will display warnings, shutdown and engine status information on the back-lit LCD screen, illuminated LEDs and remote PC. The module includes USB connection and dedicated DSENet terminals for system expansion. The module is compatible with electronic (CAN) and non-electronic (magnetic pick-up/alternator sensing) engines and offers an extensive number of flexible inputs, outputs and extensive engine protections so the system can be easily adapted to meet the most demanding industry requirements. The extensive list of features includes enhanced event and performance monitoring, remote communications & PLC ?functionality. The modules can be easily configured using the DSE Configuration Suite PC software. Selected front panel editing is also available. OVERALL SIZE 216 mm x 158 mm x 43 mm (8.5” x 6.2” x 1.5”) PANEL CUTOUT SIZE 184 mm x 137 mm (7.2” x 5.3”) MAXIMUM PANEL THICKNESS 8.0 mm (0.3”) WEIGHT 0.5kg PRODUCT VARIANTS 6110-05 - 6110 MKIII Auto Start Control Module

• DSE6110 Original - Made in UK. *Gasket not included
• The DSE6110-05 is an automatic start control module
• Support for 0-10 V & 4-20mA oil pressure senders. Heated display option
• Provides convenience of monitoring and protection of the generator or monitoring of the load current
• Tier 4 ECO engine support including exhaust fluids & filters. CAN, MPU & alternator speed sensing (selectable depending on engine type)
