Ball Screw with nut Machine Parts 2pcs HGR20 Linear Guides+4pcs HGH20CA Blocks Carriages+1pcs Ball Screw Kit SFU1605 with 8mm Coupler Router(550mm)

1. Ball screws feature face machining and are equipped with ball nuts, resulting in minimal starting torque and ease of use. 2. They are compact and easy to install and remove.Fine workmanship and full-body hardening ensure high hardness, wear resistance, and durability.3. Easily converts rotary motion into linear motion for smooth operation.Specifications:Model: SFU1605 HGR20Guide rail width or diameter: 20MMBall screw accuracy: C7Screw diameter: 16mmPitch lead: 5mmLinear guide: HGR20Description:High transmission efficiency, high positioning accuracy, good repeatability of positioning accuracy, long life, high rigidity, good transmission reversibility, bright surface, high matching accuracy, easy and light movement of the slider. Made of high-quality steel, wear-resistant, can meet high load capacity requirements. Easy to assemble Aluminum support rails with pre-drilled holes for easy installation.Packing list:2pcs HGR20 linear guide4pcs HGH20CA slider1pcs SFU1605 ball screw with nut1set BKBF12 support seat1pcs DSG16H nut seat1pcs coupling D25L30-8*10mm

• 1. Ball screws offer excellent wear resistance, low operating noise, and high transmission efficiency.
• 2. They provide more precise positioning, eliminate stick-slip effects, generate less heat, and require less drive power.
• 3. They are suitable for machining centers, CNC machine tools, mechanical equipment, and transmission equipment.
• 1. Large lead and high-speed movement, reducing movement time, more durable and stable
• 2. Waist-shaped nut, metal reverser, adjustable preload
• 3. Ultra-quiet, high wear resistance, high precision and high hardness
• 4. Smooth and non-stuck, long service life
