Industrial Heater Touch-Safe Heater CS 060 Series 50W-150W with CE Approved

Product Feature : 1. Low surface temperature 2. Quick mounting due to clip fixing 3. Double insulated (plastic) 4. Wide voltage range 5. Small size Touchsafe heater for the use in enclosures with electrical/electronical components.The design of the heater supports the natural convection which results in a high air current of warm air.The surface temperatures on the accessible side surfaces of the housing are kept down as a result of the heater design.This model with plugin thermostat requiring no additional wiring. The heaters are designed for permanent .This heater is also available in a version without thermostat (CS 060) Technical Datas Operating voltage 120-240V AC/DC (min .110V max.265V) Heating capacity see table Heater element PTC resistor-temperature limiting Surface temperature <80°c(176°F)except upper protective grille Connection 4-pole terminal 2.5mm2 torpue 0.8Nm max. Casing Plastic according to UL94-V-0,black Mounting clip for 35mm DIN rail, en 50022 Fitting position Vertical Operating storage temperature -20 to +70°c(-4 to +158°F)/-45 to +70°c(-49 to +158°F) Protection type/protection class IP20/11 (double insulated) Apporovals VDE+UL File No.E15057(according to UL499 in combination with UL508A) Note other voltages on request Operating with volta
