Satco S18420 8.5W PLL LED Lamp, 2G11 Base, Ballast Bypass Type B, Selectable CCT 3000K to 6500K Soft White to Daylight, 930-980 Lumens, Frost, 120-277V, Damp Location, Shatter Proof (2 Pack)
Product details
| Management number | 213610235 | Release Date | 2026/04/12 | List Price | $13.20 | Model Number | 213610235 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Satco S18420 is an 8.5W PLL LED lamp designed for ballast bypass (Type B) installations in compatible fixtures. It uses a 2G11 base and operates on 120-277V for retrofit projects where eliminating the ballast supports more consistent operation. This lamp is CCT selectable, allowing selection of 3000K, 3500K, 4000K, 5000K, or 6500K at installation. Light output ranges from 930 to 980 lumens depending on the selected color temperature, with a 115 degree beam angle to support practical distribution in utility and general illumination spaces. The PET coated shatter proof construction and glass material support durability, and the lamp is rated for enclosed fixtures and damp locations for broader indoor application coverage. Rated life is 50000 hours with 0.9 power factor, 20% total harmonic distortion, and built in surge protection of 0.5KV. Compliance and safety support includes FCC compliance, RoHS compliance, NSF approval, and multiple safety listings including cRUus recognized component and cULus certified and classified. Installation note: not for use in vapor tight fixtures.
- Upgrade PLL fixtures with a Satco 8.5W LED lamp built for ballast bypass Type B wiring, helping remove the ballast from the system for more direct operation. This retrofit approach supports consistent performance in utility spaces while providing an 18W fluorescent equivalent option for energy savings.
- Select the light color that fits the space using CCT selectable options of 3000K, 3500K, 4000K, 5000K, or 6500K, covering soft white through daylight in one lamp. This flexibility helps maintenance teams standardize on one SKU while still meeting different area requirements.
- Get useful brightness with output that ranges from 930 to 980 lumens depending on the chosen CCT, paired with a 115 degree beam angle for practical spread. This supports general illumination in corridors, back rooms, and work areas where balanced distribution is more important than narrow beam focus.
- Improve durability and handling confidence with PET coated shatter proof construction and a frost finish, supporting environments where lamps may be exposed during maintenance. The lamp is rated for enclosed fixtures and damp locations, expanding placement options across indoor applications.
- Built for dependable service with 50000 rated hours, 0.9 power factor, 20% total harmonic distortion, and built in 0.5KV surge protection. Compliance coverage includes NSF approval, FCC compliance, RoHS compliance, and cULus certified and classified listings plus cRUus recognition for specification driven projects.
| Voltage | 120 Volts |
|---|---|
| Wattage | 8.5 watts |
| Brand Name | Satco |
| Brightness | 980 Lumen |
| Light Type | LED |
| Unit Count | 2.0 Count |
| Manufacturer | Satco |
| Power Source | AC |
| Material Type | Glass |
| Item Type Name | LED BULB |
| Number of Items | 2 |
| Package Quantity | 2 |
| Color Temperature | 6500 Kelvin |
| Light Source Type | LED |
| Additional Features | Meet project documentation and compliance needs with published specifications and photometrics for multiple CCT settings. Performance and credential details include built in 0.5KV surge protection, NSF approval, FCC compliance, RoHS compliance, and safety listings including cRUus and cULus certified and classified., Operate reliably in indoor environments with a damp location rating and temperature range of -20C (-4F) to +45C (+113F). The lamp is rated for enclosed fixtures when used in appropriate housings, and installation notes specify it is not for use in vapor tight fixtures to prevent misapplication., Plan electrical upgrades more predictably with ballast bypass Type B operation that removes ballast variables from the circuit, helping reduce ballast related failure points. The wide 120-277V operating range supports broader deployment across mixed voltage buildings without changing the lamp., Reduce maintenance cycles with an LED PLL lamp rated for 50000 hours, helping cut relamping frequency compared to shorter life legacy lamps. This supports facilities that need stable light output over time and want fewer service interruptions in linear or plug in style fixture locations., Support phased retrofits by using one CCT selectable lamp that can be tuned during installation to match different rooms, lighting plans, or updated standards. This can simplify inventory management by reducing the need to stock multiple fixed CCT versions for the same base and form factor. |
| Included Components | Bulb included |
| Color Rendering Index | 90.00 |
| Specific Uses For Product | General purpose |
