2.2KW ER20 80mm 220v/380v Metal Working Water Cooled Spindle Motor 300HZ 4000-9000rpm Milling Machine
Product details
| Management number | 213596261 | Release Date | 2026/04/12 | List Price | $287.69 | Model Number | 213596261 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
1pcs & 22KW ER20 D80 Metal working Water cooled spindle motor 40009000rpmBasic parameterSize: 100x251.2mm (Middle body diameter:100mmxLength:257.2mm)Speed Ways: Through 3-phase output inverter and adjust the inverter frequenc to change the spindle speed.Cooling: Water coolingPower Interface: Optional H20-4 pins waterproof air plugs. The air plugs marked "1 ","2"," 3"," 4", "1 ","2 ","3" were connected to inverter (U, V, W), 4 connected inverter ground.Power: 2.2kwVoltage: 220v/380vCurrent: 10A/6AFrequenc: 300HzSpeed: 4000-9000rpmPole: 4Runout Off: Less than 0.01mmDiameter(mm): 804pcs Ceramic Ball Bearings (fully sealed angular contact bearings)Collet: ER20Advantage:Longer length make the torque bigger,more powerful. Carefull assembly make the spindle more precisional. Precision 0.01mm.Coaxial degree less than 0.0025mm.Certification : CEOrigin : Mainland ChinaDrive : MotorMaximum Torque : 2.34N.mOperating Speed : 4000-9000rpmModel Number : 2.2KW ER20 D80Application : Milling
- CPBGXJZD 2.2KW ER20 80mm 220v/380v Metal Working Water Cooled Spindle Motor 300HZ 4000-9000rpm Milling Machine
| Model | OETHEOATG |
|---|---|
| Brand Name | CPBGXJZD |
| Model Name | OETHEOATG |
| Manufacturer | CPBGXJZD |
