Mini Mill Belt Drive Conversion Kit - Easy to Install and Quieter Operation - No More Broken Gears, LittleMachineShop.com (2560)

This mini mill belt drive conversion kit provides an easy-to-install alternative to the noisy and fragile factory-installed gears that drive the spindle on the mini mill. This kit is CNC-machined from the highest quality materials. Designed to run full-time, it is built to last. The CNC belt drive conversion kit includes one belt. Change speeds without any tools. Simply remove the guard, loosen the lever locks and move the belt from one pair of pulleys to the other. Low speed range is 0-1700 RPM. High speed range is 0-4300 RPM. The installation is bolt-on and takes about 20 minutes. The small pulley has a 9 mm bore with a 3 mm keyway. The large pulley has a 30 mm bore with a 5 mm keyway. If your shafts don't match these values, then this belt drive will not fit your mill. This product works with the following mills - don't expect it to fit other machines: - Bolton XJ9510 Mill/Drill - Grizzly G8689 Mini Milling Machine - Hare & Forbes HM-10 Mill/Drill - Princess Auto 8507667 Powerfist Mini Mill - SIEG X2-MT3 Mini Mill - Micro-Mark 82573 MicroLux Milling Machine - BusyBee CX605 Craftex Mini Mill - Cummins (Tools Now) 7877 Mini Mill - Harbor Freight 44991 Central Machinery Mill/Drill - Homier 03947 Speedway Mini Mill - Northern Tool 49657 KLUTCH Mini Mill - SIEG X2-R8 Mini Mill - Travers Tools OT2213 OTMT Mini Mill - WEN 33013 WEN Mini Mill - BusyBee CX705 Craftex Lathe Mill Combo - Grizzly G0516 Lathe Mill Combo - SIEG M6 Multi-purpose Machine

• Compatibility: This product is designed to work across a broad range of metalworking machines including most top brand names. Please look at our images to see a list of compatible machines. The list of machines are those where the machines' specification ensure compatibility. If you don’t see your machine in the list, it is almost certain this product will NOT WORK on your machine. In this event, please contact us before purchasing, as we may have alternate options.
• Compatibility 2: The small pulley has a 9 mm bore with a 3 mm keyway. The large pulley has a 30 mm bore with a 5 mm keyway. If your shafts don't match these values, then this belt drive will not fit your mill.
• Quieter Operation: This mini mill belt drive conversion kit provides an easy-to-install alternative to the noisy and fragile factory-installed gears that drive the spindle on the mini mill.
• Spindle Speed: Change speeds without any tools. Simply remove the guard, loosen the lever locks and move the belt from one pair of pulleys to the other. Low speed range is 0-1700 RPM. High speed range is 0-4300 RPM.
• Easy installation: This conversion kit is made for easy hassle free installation. The installation is bolt-on and takes approximately 20 minutes.
