HGLRC Forward F4 AIO Flight Control Flight Control Board for FPV Racing Drone RC Quadcopters Multirotors
Product details
| Management number | 213546397 | Release Date | 2026/04/12 | List Price | $36.00 | Model Number | 213546397 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specification Model: Forward F4 AIO Flight Control CPU: STM32F405 MPU: MPU6000-SPI Direct welding ESC PDB Black Box: No dataflash chip found Input Voltage: 3-6S Lipo Copper foil thickness: 3OZ * 6 Maximum current: 280A Built-in Betaflight OSD to adjust PID BEC Output: 5V@3A, 8V@1.5A Size: 31.0x34.5mm board, 20.0mm mounting holes (M2) Weight:10.4g Recommended ESCs:HGLRC T-Rex 35A BLHeli32 ESC HGLRC Forward BLHeli_32 50A ESC Individual ESCs or 4-in-1 ESC Package Included 1x HGLRC Forward F4 AIO Flight Control 1x SH1.0 8PIN 60MM Cable
- Support 3-6S lipo battery which maximum current is 280A
- Direct welding ESC PDB
- Size: 31.0x34.5mm board, 20.0mm mounting holes (M2) Light weight is10.4g
| UPC | 734391069741 |
|---|---|
| Brand Name | HGLTECH |
| Part Number | HGL-FC015 |
| Manufacturer | HGLTECH |
