BENEWAKE TF03-100 Industrial Long Range LiDAR Sensor Laser Radar, 100m Measurement IP67 Waterproof, UART/RS232/RS485/CAN Interface, for UAV, Industrial Safety and Traffic Flow Detection (UART)

Product Description BENEWAKE TF03-100: An Industrial-Grade LiDAR Solution Engineered for Professional Applications The Benewake TF03-100 is a high-performance single-point LiDAR distance sensor. Building on the strengths of the TF series, it offers enhanced range and environmental robustness, providing a reliable distance sensing solution for industrial automation, UAVs, intelligent transportation, and beyond. Key Advantages: Reliable Distance Data:​ Delivers accurate, continuous distance information up to 100m, giving your equipment precise "visual" perception. Superior Environmental Adaptability:​ The IP67 rating ensures stable operation in dusty, rainy, and other harsh conditions. Its advanced anti-interference algorithm effectively mitigates the impact of strong outdoor light and weather changes. Powerful Integration Flexibility:​ Multiple interface options and configurable parameters allow engineers to easily connect the TF03-100 to main controllers, flight controllers (e.g., F4 FC), or industrial PLC systems for rapid development. Product Specification Product Model​:Benewake TF03-100 Detection Range​:Up to 100 meters Ranging Accuracy​:±10cm (within 10m) or ±1% (beyond 10m) Field of View​:0.5° Communication Interface​:UART, CAN, RS232, RS485 Protection Rating​:IP67 (Dustproof and Waterproof, suitable for harsh environments) Operating Voltage​:5V DC Operating Temperature​:-25°C to +60°C Product Dimensions​:44mm × 43mm × 32mm Typical Applications: Unmanned Aerial Vehicles (UAVs):​ Enables precise terrain following, automatic takeoff/landing, and altitude hold. Industrial Safety:​ Used for collision warning and safety zone monitoring on cranes and automated machinery. Intelligent Transportation:​ Vehicle detection, trigger for photography, and traffic flow counting. Level Measurement:​ Monitors material height in silos and storage tanks.

• Industrial Long-Range Measurement:​ The TF03-100 LiDAR sensor features a long detection range of up to 100m with high accuracy, ideal for UAV altitude hold, industrial safety warnings, traffic flow statistics, and more.
• Rugged & Built for Harsh Environments:​ With an IP67 rating, metal housing, and high-transmittance glass, it is dustproof, waterproof, and operates reliably in rain, fog, snow, and temperatures from -25°C to 60°C. It resists ambient light interference up to 100klux.
• Flexible Interfaces & Customizable Configuration:​ Offers multiple communication interfaces (UART, CAN, RS232, RS485) and supports custom parameter and mode settings for easy integration into various applications.
• High Precision & Reliability:​ Based on Time-of-Flight (ToF) principle with compensation algorithms, it ensures centimeter-level resolution and reliable performance even in challenging conditions like strong light.
• Compact Design for Easy Integration:​ Features a small form factor (44 * 43 * 32mm) and light weight, making it easy to install on drones, smart devices, and industrial equipment with space and weight constraints.
