4G LTE USB WiFi Modem, LTE/4G 150 Mbps Mobile Module with SIM Card Slot, High Speed Portable Travel Hotspot Mini Router Supports UART for PC, Industrial Computer

Specification: Item Type: SIM7600G‑H 4G DONGLE Product Parameters Material: ABS Model: SIM7600G-H LTE-TDD: B34/B38/B39/B40/B4l LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66 3G Frequency Band: UMTS/HSDPA/HSPA+: B1/B2/B4/B5/B6/B8/B19 2G Frequency Band: GSM/GPRS/: 850/900/1800/1900MHz GNSS: Support GPS, Beidou, Glonass, LBS base station positioning Applicable Area: Universal Data : LTE Cat-4：150Mbps(DL)/50Mbps(UL) 3G(HSPA+)：42Mbps(DL)/5.76Mbps(UL) 2G()：236.8Kbps(DL)/236.8Kbps(UL) 2G(GPRS)：85.6Kbps(DL)/85.6Kbps(UL) Software Function: Operating System:for ,for Linux Letter of Agreement: /IP/IPV4/IPV6/Multi-PDP/FTP/FTPS/HTTP/HTTPS/DNS Internet Access: NDIS/RNDIS/PPP Short Message (SMS): Support MT, MO, CB, Text, PDU Hardware Description: Communication Interface: USB/UART UART Communication Baud Rate: 300bps-4mbps (default is L15200bps) Indicator: NET: Internet Indicator STA: Status Indicator PWR: Power Indicator Support SIM Card: Nano SIM Card (1.8V / 3V) (Card Not Included) Antenna Interface: LTE Supply Voltage: 5V Logic Voltage: 3.3V Package List: 1 x SIM7600G‑H 4G DONGLE 1 x LTE Antenna 1 x USB Extension Cable 5 x Screws 1 x Screwdriver 1 x Connection Line

• Industrial Grade Design: SIM7600G‑H 4G DONGLE LTE USB adapter adopts industrial grade 4G communication solution, equipped with SIM7600G‑H module, which makes the communication stable and . LTE USB adapter with SIM card slot, support Nano SIM card,(not include ) Driver download site : www..net/wiki/SIM7600G-H_4G_DONGLE
• Need Driver : USB network module compatible with /Linux systems, just plug in the USB port, install the driver for configuration, and you can achieve high-speed 4G networking. (Please customer service to send the driver), LTE USB modem with rotatable antenna, the antenna adopts a flexible structure design and supports multi dimensional rotation.
• Three Indicator Lights: SIM7600G‑H 4G DONGLE Module has three data indicator lights, you can easily see the working status, NET: internet indicator, SAT: status indicator, PWR: power indicator.
• 2 Interface Communication: 4G DONGLE module supports cloud communication, supports USB and UART two interface communication, supports /UDP/FTP/FTPS/HTTP/HTTPS and other communication protocols.
• Application Scenario: SIM7600G‑H 4G DONGLE can be used for industrial computer networking, PC Internet access, shared/unmanned self service equipment, open source hardware networking, industrial Internet of Things.
