GKG DTK7 12 Pin Deutsch Connector Kit,6 Sets DT Deutsch Connector 12 Pin,Gray Waterproof Electrical Wire Connectors with 74 Pairs Size 16 Solid Contacts 14-20AWG for Car,Truck and Boat,etc
Product details
| Management number | 211845083 | Release Date | 2026/04/06 | List Price | $13.88 | Model Number | 211845083 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Kit Contents:6 sets 12 pin deutsch connector(plug model:DT06-12S,receptacle model:DT06-12P),37 pairs14-16AWG solid contacts(with green ring),37 pairs 16-20AWG solid contacts,6 pairs wedge locks and 20pcs white sealing plugs(part number:114017),totaling 192 pieces
- 12 Pin Deutsch Connectors:The DT series connectors are made of flame-retardant PA66 nylon,meeting both IP68 waterproof and dustproof standards and the UL94-V0 flame retardancy standard.They are high-temperature resistant and highly vibration-resistant,capable of withstanding 20G sinusoidal vibrations(10-2000HZ)without unlocking or separating.They can endure up to 100 mating cycles without mechanical damage.Temperature resistance range: -40°C to 125°C
- 14-20AWG Solid Contacts:Nickel-plated solid contacts achieve an insulation resistance of up to 1000 megaohms at 25°C.They are suitable for size 16# 14-20AWG wires,with a continuous current rating of up to 13 amps per contact
- 3 Upgraded Designs:Firstly,the 'P012' enhanced seal ring adds thickness for an ultra-tight seal.And then,The plug end has a groove design to securely hold the seal and prevent separation during assembly.Finally,The wedgelock has an internal hook design,preventing separation and enhancing stability
- Wide Applications:The GKG DT deutsch connector 12 pin kit is specifically designed to withstand various harsh environments,such as humidity,dust,high temperatures and low temperatures.It is suitable for various applications, including engines,engine rooms,chassis and driver cabins
- Note:When assembling the 12 pin deutsch connector,ensure that the A-key of the plug aligns with the A-key slot of the receptacle before installation
- Lifetime Support:Enjoy lifetime technical support and replacements.The GKG team is always available to assist you with any questions regarding deutsch connector kit 12 pin—whenever you need us
| Brand | GKG |
|---|---|
| Model | DTK7 |
| Item Weight | 15.8 ounces |
| Manufacturer | GKG |
| Item model number | DTK7 |
| Product Dimensions | 7.88 x 5.12 x 1.78 inches |
| Manufacturer Part Number | DT04-12P,DT06-12S |
