Digital millioh Meter 3 1/2 4 Wire Test with LCD Backlight Low Resistance multimeter 6 Range 0.01 mΩ - 2 kΩ Accuracy Measuring Instrument VC 480 C + for Resistance Transformer mot

1. Digital ohmmeter with large LCD display can be read very clearly. 2. Four wire tests that can test extremely low resistance. 3. Accurate measurement of conductors, electrical heating elements, and solder points. It is widely used in building protection networks, leveling the rings of glass curtain walls, and in communication antennas. High measurement range of 0.01 mΩ to 2 kΩ in the 4. 6 range 5. HOLD key to hold the data. 6. LCD with backlight easy to see even in dark places. 7. Connection to external power supply. 8. Strong anti-magnetism and anti-jamming function. 9. Full function protection. Model: VC480C + Low battery indication: about 7.5 V or less Functional protection: √ Sampling rate: 3 times / sec Operation mode: Manual range Maximum number of indicators: 1999 Liquid crystal size: 75 × 52 mm Power supply: 6 x 1.5 V AAA battery (not included), or external DC 9 V power supply Power consumption: about 6 mA quiescent current Range Accuracy Resolution Measuring current 20 mΩ ± (0.5% + 3) 0.01 mΩ Approx. 100 mA 200 mΩ ± (0.5% + 3) 0.1 mΩ Approx 50 mA 2 Ω ± (0.5% + 3) 1 mΩ Approx 50 mA 20 Ω ± (0.5% + 3) 10 mΩ Approx 50 mA 200 Ω ± (0.5% + 3) 100 mΩ Approx 50 mA 2 kΩ ± (0.5% + 3) 1 Ω Approx 50 mA The products of our shop have many characteristics, you are welcome to visit our shop to visit other style products, if you have any questions, please feel free to ask questions, we will reply to your questions within 12 hours, I wish you a happy life.

• Digital ohmmeter with large LCD display can be read very clearly. With backlight easy to see even in dark places.
• Accurate measurement of conductors, electric heating elements, and solder points. It is widely used in building protection networks, leveling the rings of glass curtain walls, and in communication antennas.
• High measurement range of 0.01 mΩ to 2 kΩ in the 6 range.
• Four wire tests that can test extremely low resistance.
