Hydraulic Control Valve with Joystick, 1 Spool 11GPM Hydraulic Directional Valve for Log Splitters, Tractors Loaders Black
Product details
| Management number | 211103549 | Release Date | 2026/04/04 | List Price | $20.90 | Model Number | 211103549 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
[APPLICATION] Suitable for log splitters, tractors loaders, tanks, small tractors, and etc.
- [APPLICATION] Closed center valve, and suitable for log splitters, tractors loaders, tanks, small tractors, and etc.
- [FUNCTION] Used to raise and lower the laoder, and dump and retract the bucket. The hydraulic lever supports automatic reset.
- [PROPERTIES] The P and T ports feature 7/8-14 UNF (SAE #10) oil ports, while the A and B ports feature 3/4-14 UNF (SAE #8) oil ports.
- [HIGH QUALITY] The Max Relief Valve Range is 3600 PSI, and the Max Flow Rate is 11 GPM.
- [WARRANTY] We provide 2-year warranty and 24-hour frendly customer service.
| Size | 11GPM 1 Spool |
|---|---|
| Brand Name | INPANOLS |
| Unit Count | 1.0 Count |
| Valve Type | Hydraulic Directional Valve |
| Thread Size | 3/4-16 UNF, 7/8-16 UNF |
| Thread Type | UNF |
| Manufacturer | INPANOLS |
| Model Number | 1SP-1 |
| Material Type | Steel |
| Item Type Name | Hydraulic Directional Control Valve |
| Item Dimensions | 5.1 x 4 x 8.8 inches |
| Number of Ports | 4 |
| Maximum Pressure | 3600 Pound per Square Inch |
| Specification Met | sae |
| Included Components | Hydraulic Control Valve |
| Inlet Connection Size | 0.88 Inches |
| Inlet Connection Type | 【1】A & B Ports: #8 SAE (3/4-16 UNF). 【2】P & T Ports: #10 SAE (7/8-16 UNF) |
| Outlet Connection Size | 0.75 Inches |
| Outlet Connection Type | SAE |
