RIGOL Digital Oscilloscope DHO804 70 MHz 4-Ch 1.25 GSa/s 12-bit 25 Mpts UltraAcquire 1,000,000 wfms/s 7" Touch LAN/USB/HDMI Web Control SCPI for Power Ripple Embedded Debug
Product details
| Management number | 210908484 | Release Date | 2026/04/04 | List Price | $175.60 | Model Number | 210908484 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【Key Specs】70 MHz digital oscilloscope with 4 analog channels, 1.25 GSa/s sampling, 12-bit vertical resolution and up to 25 Mpts memory depth—helps correlate multiple rails and timing signals with fine vertical detail.
- 【UltraAcquire & Search】UltraAcquire up to 1,000,000 wfms/s; 256-level intensity grading plus waveform search/navigation helps find intermittent glitches and review anomalies quickly using event/time/frame navigation.
- 【FFT & Decode】Peak detect captures glitches down to 1.6 ns; math includes FFT up to 1 Mpts, filters, and 41 automatic measurements. Standard serial trigger/decode supports CAN, RS232/UART, I2C, SPI and 4-bit parallel decode using analog channels.
- 【Connectivity & SCPI】LAN supports LXI‑C, browser Web Control and standard SCPI commands. USB Host/Device and HDMI improve documentation, data export and external display for lab or teaching use.
- 【Applications】Digital oscilloscope for switching power ripple/noise checks, embedded bring-up, sensor interface validation and protocol troubleshooting; 7" 1024×600 touch screen and Flex Knob support fast daily measurements.
| Item Weight | 3.92 pounds |
|---|---|
| Manufacturer | RIGOL |
| Item model number | DHO804 |
| Product Dimensions | 10.45 x 3.05 x 6.37 inches |
