AT4708V 8 Channel PT100 Heat Resistance Supported Multi-Channel Temperature Meter

AT47V series multi - channel temperature meter adopt high preformance ARM micro processor control with 7 inch color LCD display & touch screen.it's convinence to check temperature values, temperature variation curve,bar graph etc. can collection multi-channel temperature data at the same time, upper/lower beep and communication transport. AT47V series can collection 64 channel temperature data, compatible with a various of temperature sensors, additional support P100,CU50,DCV measurement, fast response, stable data, with broken thermocouple check function. channel to channel isolation DC:350V. each channel can set up separately and correction indepentdently. AT47V support RS-232 communication, sampling, analysis and printing by software of computer. Support USB disc storage, store sampling data on real time. user can correction each channel of dataindepentdently. Model: AT4708V Function Support: PT100, CU50, DCV Graded Thermocouple: Thermocouple: J/K/T/E/S/N/B/R, Heat Resistant: PT100 Accuracy: ±0.2% ±2 dgt (excluding thermocouple) PT100: ±0.6°C CU50: ±0.6 Range : 200°C ~1300°C (varies according to scale) Test Voltage : 100.00V 0.05% 10.000V 0.05% 1.0000V 0.05% 100.00mV 0.1% Thermocouple Resolution: 0.1℃; Thermal Resistance 0.01 Channels: 8 Scanning speed: 500ms, 1s Calibration: Error correction per channel Interface: RS232C USB flash disk

• Origin:Mainland China
• DIY Supplies:ELECTRICAL
• Certification:NONE
